Name: Game Controller PCB Board
Brand: Freconn-Smt
Rating: 5 (1 reviews)

Description

Product Overview

Our game console PCB and integrated PCBA control motherboards are the core signal transmission and processing hub for all consumer and amusement gaming equipment. We produce high-speed multi-layer rigid FR4 circuit boards, compatible with mainstream home game hosts, portable handheld game consoles, coin-operated arcade machines, claw crane game equipment, wireless gamepads and game cartridge circuit boards. Optimized HDI high-density interconnection layout supports 4K high frame rate signal output, stable low-latency transmission for graphics, audio and control signals. Every circuit board undergoes 100% open-short circuit test + full function aging test before delivery, effectively reducing equipment crash, screen flicker and signal lag faults during long-time gaming operation.

Core Advantages

Low-Loss High-Speed Signal Transmission
Adopt high Tg low Dk FR4 material, optimized differential wiring design, signal loss controlled within ultra-low range, effectively eliminate picture stutter, input delay and audio distortion. Multi-layer shielding structure greatly reduces electromagnetic interference, stable operation even under long-hour high-load gaming.
Efficient Heat Dissipation & Complete Safety Protection
Dense thermal vias and large-area copper laying design quickly export CPU/GPU heat, avoid overheating shutdown and board warpage. Equipped with overvoltage, overcurrent, short-circuit and surge protection circuit, prevent chip burnout caused by unstable power supply. Arcade version supports dustproof and moisture-proof conformal coating optional for long-time commercial use.
Multi-Board Solution for All Gaming Scenarios

Standard FR4 Multi-Layer PCB: Main control board for home game consoles, arcade mainboard, high mechanical strength, UL94 V0 flame retardant
Thin Small PCB: Wireless game controller, handheld game auxiliary board, compact layout, light weight
Aluminum Substrate PCB (Optional): For high-power gaming equipment with strict heat dissipation requirements

Export-Grade Environmental Quality Standard
All raw materials pass RoHS & REACH hazardous substance testing, factory fully implements ISO9001 quality management system, low radiation, meets EU, US and global electronic product export standards.

Full One-Stop Custom Service

We cover the whole R&D and production chain to cut your development cycle and procurement cost:

Hardware: Schematic drawing, PCB layout design, Gerber/BOM file modification, rapid prototype sampling
Assembly: Automatic SMT patch, DIP plug-in welding, game firmware burning, full function aging test
Software: Custom multi-mode game program, Bluetooth/WiFi wireless linkage, controller response speed parameter adjustment
OEM & ODM Customization: Board size, outline shape, silkscreen logo, circuit power, signal channel and function modes all customizable

Wide Application Compatibility

Our gaming circuit boards fit almost all mainstream game devices:

✅ PS / Xbox / Switch Home Game Console Mainboard

✅ Portable Handheld Game Players & Mini Game Boxes

✅ Coin Operated Arcade Multi-Game Motherboard

✅ Claw Crane, Mario, Slot Amusement Game Equipment

✅ Wireless Bluetooth Gamepad & Joystick Control PCB

✅ Game Cartridge, Display Screen & Audio Auxiliary Circuit Boards

Product Specifications

Base Material: High Tg FR4 / Aluminum MCPCB (optional)
Layers: 2–12 layers customizable
Copper Thickness: 0.5oz–3oz
Surface Finish: OSP, Lead-free HASL, ENIG Immersion Gold, Immersion Silver
Board Thickness: 0.4mm–3.0mm
Line Width/Spacing: Min 0.075mm HDI precision wiring
Certification: RoHS, REACH, ISO9001, UL
MOQ: 1pc for sample, mass production quantity negotiable
Lead Time: 3–7 working days for prototypes, 8–18 working days for bulk orders

Why Choose Us?

Professional electronic R&D team with over 10 years gaming equipment PCB development experience, familiar with host, arcade and controller circuit logic
Dust-free automatic SMT production workshop, stable monthly output over 150,000 pieces, delivery schedule guaranteed
Double strict inspection: electrical connectivity test + 24-hour aging full inspection, ultra-low defective rate
Lifetime free technical after-sales support, free circuit parameter debugging and firmware upgrade guidance
Flexible cooperation mode, support startup gaming brands, amusement factory and electronic repair merchants
